Chemically etched PTFE sheets by National Fluoromers – manufacturer, supplier & exporter

PTFE sheets
Enquiry Now
technical specifications
Property Value
Base material Virgin or filled PTFE
Etched surface One side / both sides
Thickness range 0.5 mm to 100 mm
Sheet size Up to 1200 mm × 1200 mm
Color of etched surface Brown/charcoal (etched side)

National Fluoromers is a leading manufacturer and exporter of chemically processed PTFE sheets, also known as etched PTFE sheets. These sheets are specially treated to enable bonding with adhesives, rubber, metals, and composite materials—overcoming the natural non-stick property of virgin ptfe.

Whether you need a reliable liner, laminated gasket material, or bonded insulation layer, our chemically etched PTFE sheets provide the perfect balance of durability, bondability, and chemical resistance.

what is a chemically processed PTFE sheet?

PTFEis inherently non-stick, making it difficult to bond using conventional adhesives. Chemically processed PTFE sheets are surface-treated using a controlled chemical etching process that modifies one or both sides of the sheet. This process roughens the surface at a molecular level, creating a darkened, activated layer that bonds effectively to other materials.

These sheets retain all the physical and thermal advantages of PTFEwhile gaining adhesive compatibility.

key features
  • One-side or two-side etched surface: Ensures strong adhesion with glues, rubbers, and metals.
  • Retains PTFE properties: Chemical inertness, high temperature resistance, and low friction surface.
  • Improved bonding performance: Ideal for multi-layered composites.
  • Wide temperature range: From –200°c to +260°c.
  • Customizable surface treatment: Based on bonding requirements.
advantages
  • Enables PTFE to be glued or laminated
  • Suitable for precision gaskets and seals
  • High mechanical and dielectric strength
  • Resistant to UV, weathering, and harsh chemicals
  • Long-lasting in both static and dynamic applications
applications of chemically processed PTFE sheets
  • Bonded gaskets in chemical and pharmaceutical industries
  • Anti-corrosive linings in tanks and ducts
  • PTFE-rubber composite seals
  • Bonded electrical insulators
  • Wear-resistant strips in machinery
  • Non-stick layers in laminates
industries we serve
  • Chemical & petrochemical
  • Pharmaceutical & biotech
  • Electronics & electrical
  • Automotive & aerospace
  • Food processing & packaging
  • Construction & infrastructure
why choose National Fluoromers
  • Custom sheet sizes and dual-surface etching available
  • Fast turnaround and global export capability
customization & supply options
  • Single-side or double-side etched PTFE sheets
  • Custom-cut dimensions and roll formats
  • Etching available on virgin or filled PTFE(glass, bronze, carbon, etc.)
Trust National Fluoromers for top-grade chemically processed PTFE sheets with guaranteed adhesion and chemical resistance.

Our technical team is ready to guide you with the right solution.
